• Distributed Echo Cancellation® and noise cancellation along with full-duplex performance and automatic level controls guarantee your conference calls to be natural with unmatched audio clarity without any distractions.
  • CHAT 50 is versatile for use with your PC and mobile phones and your enterprise telephones to experience crystal-clear HDConference audio using your convenience device with hands-free comfort.
  • Sleek enough for professional office environment, yet rugged enough to toss in your bag and take on the road. Powered through USB, CHAT 50 is a truly plug and-play compact device.
  • Perfect for use at your desktop, home office, executive office, huddle-spaces.

Connections

  • USB: Version 2.0 Compatible
  • Type: Mini-B Female

External Audio

  • Type: 3.5 mm (1/8”) Mini-plug
  • Tip: Line Output
  • Ring: Line Input
  • sleeve: Ground

Controls

  • Volume Up
  • Volume Down
  • Microphone Mute

Compatibility

  • Audio: Windows 8, 10 MAC OSX Linux
  • software: Windows 8, 10

Audio

  • Speaker: Bandwidth: 220 Hz - 14 kHz Max Output Level: 80 dB SPL @ 1 foot (0.30 meters)
  • Microphone: Bandwidth: 50 Hz - kHz
  • line Output: Frequency Response: 20 Hz - 20 kHz +/- 1dB Max Output Level: 0 dBu Output Impedance: 50 Ω

Processing

  • Full-Duplex
  • Acoustic Echo Cancellation (AEC)
  • Noise Cancellation (NC)
  • Line Echo Cancellation (selectable)
  • Automatic Level Control (AlC)

Power

  • USB-powered
  • 5 VDC @ 500 mA maximum
  • External Power supply 100 - 240 v AC Input 7
  • VDC @ 560 mA Output
  • Tip: Power
  • Ring: Ground

Environmental

  • Operating Temperature: 41 - 104° F (5 - 40° C)

Mechanical

  • Dimensions: (W x D x H): 3.8” x 4.1” x 1.8” (9.7 cm x 10.4 cm x 4.6 cm)
  • Weight: 0.55 lbs. (0.25 kg)

Compliance

  • FCC Class B Part 15
  • REACH
  • ICES -003
  • U/L listed
  • CE listed
  • RoHS

Model numbers

  • 910-159-001 CHAT 50 USB: CHAT 50 USB 20. Cable Quick-Start Guide
  • 910-159-002 CHAT 50 USB Plus: CHAT 50 USB 2.0 Cable Power Supply US Power Clip Cellphone Audio Cable (2.5 - 3.5 mm) Quick-Start Guide
  • 910-159-002 CHAT 50 usB Plus Int.: CHAT 50 USB 2.0 Cable Power Supply International Power Clips Cellphone Audio Cable (2.5 - 3.5 mm) Quick-Start Guide
  • 910-159-002 CHAT 50 Global Traveler: CHAT 50 USB 2.0 Cable Power Supply International Power Clips Cellphone Audio Cable (2.5 - 3.5 mm) MP3 Player Audio Cable (3.5 - 3.5 mm) Travel Case Quick-Start Guide
