COMPATIBLE WITH




Enhance Your Cloud Collaboration

Combine 120 degree field-of-view and digital zoom with your own choice of mic and speaker to enjoy an exceptional collaboration experience.

Key Highlights

  • 4K video, auto-focus, and 3x digital zoom
  • Easily mounted on monitors using standard damping rotary-shaft support
  • 120° ultra-wide angle field-of-view
  • Perfect for popular cloud-based applications such as ClearOne’s COLLABORATE® Space, Microsoft® Teams, WebEx™Zoom™, GoToMeeting™, and more
  • Wide dynamic range support for optimal image capture
  • Affordable 4K video for BYOD video conferencing, web conferencing, UC applications, and more in smaller spaces.
  • Super-high SNR with advanced 2D and 3D noise reduction
  • Full-function USB 3.0 interface for video and power
  • Control the camera’s functions via IR remote or UVC protocol

Applications

  • PC-based video conferencing
  • Web conferencing
  • Unified communications

Environments

  • Huddle spaces
  • Small meeting rooms
  • Executive Offices

Combine 120 degree field-of-view and digital zoom with your own choice of mic and speaker to enjoy an exceptional collaboration experience.

VIDEO SYSTEM

  • 4K: down-compatible with 1080p30 and 720p
  • Sensor: 1/2.5’’, CMOS, Effective Pixel: 8.29M
  • Scanning Mode: Progressive
  • Lens: Focus: f=2.8mm, FOV: 120°
  • Focus Mode: Auto Focus
  • Minimal Illumination: 0.05 Lux @ (F1.8, AGC ON)
  • Shutter: 1/30s – 1/10000s
  • White Balance: Auto, Indoor, Outdoor, One Push, Manual
  • Backlight Compensation: Supported
  • Digital Noise Reduction: 2D & 3D Digital Noise Reduction
  • Horizontal Angle of View: Wide angle up to 120°
  • Electronic Pan Tilt Zoom
  • Easy Installation: Equipped with damping rotary shaft bracket to fit almost any display, easy to install, stable and reliable

AUDIO

  • Built-in microphone array on configuration

USB Features

  • Operating Systems: Windows 7, Windows 8, Windows 8.1, Windows 10, MacOS, Linux
  • Video Formats: 4K30, 1080p30, 1080p25, 720p30, 720p25, 960x540p30, 960x540p25, 640x360p30, 640x360p25, etc.
  • USB Video Communication: UVC 1.0/1.1
  • UVC PTZ: Supported

INPUT/OUTPUT INTERFACE

  • USB Interface: 1xUSB 3.0: Type B, female

GENERIC SPECIFICATIONS

  • Input Voltage: 5v (USB power supply)
  • Current Consumption: 600 mA
  • Power Consumption: 3.0 W
  • Operating Temperature: 14°F ~ 104°F (-10°C ~ 40°C)
  • Storage Temperature: -40°F ~ 140°F (-40°C ~ 60°C)
  • MTBF: >30000 h
  • Dimensions: Weight: 0.34 kg
  • Part Number: 910-2100-006
