COLLABORATE®
Versa® 20
System including a UNITE® 20 Pro Webcam and a CHAT® 50 personal speakerphone with ClearOne’s HDConference® audio technology and HD video.
- Rich Conferencing: Portable USB speakerphone, powered by ClearOne’s market leading HDConference™ audio, enhances web conferencing, unified communications and video conferencing experience in your personal workspace with crystal-clear audio for business-class performance.
- CHAT® 50 personal speakerphone with advanced audio processing for a rich conferencing experience.
- One UNITE® 20 pro webcam 120-degree ultra-wide angle field-of-view, up to 1080p@30 Full HD, super-high SNR with advanced 2D and 3D noise reduction.
- Use with PC or laptop and web conferencing applications Microsoft® Teams, Zoom™, Webex™, Google® Meet™, and others.
- Easy Installation: Equipped with damped rotary shaftbracket to fit almost any display, easy to install, stable and reliable.
INCLUDES
- UNITE® 20 Pro Webcam
- CHAT® 50 Speakerphone
UNITE 20 PRO WEBCAM
VIDEO
- Video Format: 1080p@30fps/25fps, 720p30/25, 960x540p30/25, 640x360p30/25
- Sensor: 1/2.7 ’’, CMOS, effective pixel: 2.07 M
- Scanning mode: Progressive
- Lens: focus: f=2.8 mm, FOV: 120°
- Minimal illumination: 0.05 Lux @ (F1.8, AGC ON)
- Shutter: 1/30 s – 1/10000 s
- White balance: auto, indoor, outdoor, One-push, manual
- Backlight compensation: supported
- Digital noise reduction: 2D & 3D
AUDIO
- Built-in microphone array
COMPATIBILITY
- Operating systems: Windows® 7 (1080p and under only) or higher, Linux, MAC OS™ 10.10 or higher, Google™ Chromebook™ 29.0.1547.70 or higher
- 2.4 GHz Intel® Core 2 Duo processor or higher
- 2 GB RAM or more
- USB 2.0 port
- Color system/compression: H.265 / H.264 / MJPEG
- USB video communication protocol: UVC 1.0 - UVC 1.5 (optional)
INPUT/OUTPUT INTERFACE
- USB Interface: 1 x USB 2.0: Type A
POWER
- Input voltage: 5 V (USB power supply)
- 5 VDC @ 500 mA maximum
ENVIRONMENTAL
- Operating temperature: 14° F - 104° F (-10° C - 40° C)
MECHANICAL
- Dimensions (W x D x H): 4.65 x 1.46 x 1.21 ” (118 x 37.2 x 30.8 mm)
- Weight: 0.21 lbs (0.093 Kg) without bracket, 4.41 lbs (0.2 Kg) with bracket
SYSTEM REQUIREMENTS
- Windows 7 or higher, MAC OS 10.7 or higher
CHAT 50 SPEAKERPHONE
AUDIO
- Speaker: Bandwidth: 220 Hz - 14 kHz
- Max Output Level: 80 dB SPL @ 1 foot (0.30 meters)
- Microphone Bandwidth: 50 Hz - 7.75 kHz
- Full-Duplex Acoustic Echo Cancellation (AEC)
- Noise Cancellation (NC)
- Automatic Level Control (ALC)
COMPATIBILITY
- Audio: Windows 7, 8, 10, MAC OSX, Linux
- Software: Windows 7, 8, 10
INPUT/OUTPUT INTERFACE
- USB Mini B port
CONTROLS
- Volume Up
- Volume Down
- Microphone Mute
POWER
- USB-powered
- 5 VDC @ 500 mA maximum
ENVIRONMENTAL
- Operating Temperature: 41 °F - 104 °F (5 °C - 40 °C)
MECHANICAL
- Dimensions (W x D x H): 3.8 x 4.1 x 1.8 ” (97 x 104 x 4.6 mm)
- Weight: 0.55 lbs (0.25 Kg)
PART NUMBERS
- 910-3001-020 Collaborate Versa 20
- 910-159-001 Chat 50 Speakerphone
- 910-2100-020 UNITE 20 Pro Webcam
