- Connects to any display—compatible with all the latest 4K resolutions.
- Easily select which HDMI source is displayed using the the front panel button or the simple API command set.
- ClearOne P-Link provides audio, control, and power connectivity from the BMA 360DX using a single CAT6 cable.
- Dramatically simplifies any installation where display speakers are being used.
Part Number
- 910-3200-308
HDMI I/O
HDMI In Select
- Select HDMI In 1 or HDMI In 2 to HDMI Out
- Select HDMI LED
HDMI 2.0 In
- Standard HDMI Receptacle
- Support up to 4K @ 60 Hz video format
HDMI 2.0 Out
- Standard HDMI Receptacle
- Support up to 4K @ 60 Hz video format
Peripheral PoE
PoE In
- RJ-45 · IEEE802.3 bt compliant devices or equivalent, PoE++ - Mode A, Mode B, and 4-pair Mode
Peripheral Bus
P-Link in and Out
- Ports Type: RJ-45
- P-Link Power
- 56 V 36 W IEEE 802.3 at compliant devices or equivalent, Mode B
- Cable: Solid core 23 AWG, factory terminated Cat 6
- Distance
- Normal distance mode: Up to 200 ft (60 m)
Power LED
- Blue
Status LED
- Blue
- Red
Power Consumption
Power and Thermal
- 100-240VAC, 50/60 Hz. 120 VAC, 60 Hz @ 0.076 A
- Thermal: 15.6 BTU/hr
- 4 W typical
- Operating Temperature: 14 °F/-10 °C to 104 °F/40 °C
Dimension and Weight
Dimensions
- 6.77 x 4.21 x 1.73 ” (172 x 107 x 44 mm)
Product Weight
- 3.1 lbs (1.4 Kg)
Shipping Weight
- 4.2 lbs (1.9 Kg)
Operating Temperature
- 14 °F/-10 °C to 104 °F/40 °C
Mounting
- Brackets included for mounting underneath a table
