• AI-based smart face tracking keeps the selected presenter in the frame as they move around the room.
  • AI-based auto framing mode always keeps the entire group perfectly in view.
  • Advanced algorithms enable the lens to quickly and accurately focus.
  • Capture meetings and lecturers directly to USB for easy sharing and review with Local MP4 Recording (included in firmware v9.1.21 and later).
  • A high SNR CMOS sensor combined with 2D and 3D noise reduction algorithms provide a super clean image, even under low light conditions.
  • Seamlessly track individuals even after leaving the frame eliminating dropped connections and refocusing delays, thanks to advanced Re-Identification (ReID - included in firmware v9.1.21 and later).
  • Streams AV over IP using H.264 and H.265 video compression.
  • Can be powered by PoE (48V DC), or 12V DC power supply.
  • Control the camera’s functions via USB, Ethernet, RS-485, and RS-232.
  • Compatible with popular applications such as Microsoft® Teams, Zoom™, WebEx™, Google® Meet™, and more.

Camera

  • Video System:
    • 2160p30
    • 2160p25
    • 1080P30
    • 1080P25
  • Sensor: 1/1.8 inch, CMOS
  • Effective Pixel: 8.51M
  • Scanning Mode: Progressive
  • Lens: 20x maximum zoom, Focal length: 4.4mm – 88.5mm, F1.8 – F2.6
  • Minimal Illumination: 0.5 l ux @ (f2.0, Agc ON)
  • Shutter: 1/30s – 1/10000s
  • White Balance: Automatic, Indoor, Outdoor, One Button, Manual, Specified Color
  • Backlight Compensation: Supported
  • Digital Noise Reduction: 2D & 3D Digital Noise Reduction
  • Signal to Noise Ratio ≥55dB
  • Horizontal Angle of View: 60.7° – 3.36°
  • Vertical Angle of View: 34.1° – 1.89°
  • Horizontal Rotation Range: ±170°
  • Vertical Rotation Range: -30° – +90°
  • Pan Speed Range: 1.7° – 100°/S
  • Tilt Speed Range: 1.7° – 69.9°/S
  • H & V FLIP: Supported
  • Image Freezing: Supported
  • Number of Presets: 255
  • Preset Accuracy: 0.1°

Input/Output Interface

  • USB Interface: USB 3.0, Type C socket
  • HD Output: 1 channel, HDMI1.4b
  • Network Interface: 1 x RJ45: 10M/100M Adaptive Ethernet Port
  • Audio Interface:
    • 1-Ch 3.5mm Audio Interface
  • Communication Interface:
    • 1 x RS232 In: 8-Pin Small DIN, Maximum Distance: 30M, Protocols: VISCA/Pelco-D/ Pelco-P
    • 1 x RS232 Out: 8-Pin Small DIN, Maximum Distance: 30M, Protocols: VISCA/Pelco-D/ Pelco-P

USB Features

  • Operating Systems: Windows 7 and later
  • Color System: YUY2/MJPEG
  • Video Formats:
    • YUY2 : Max 1080P@30fps
    • MJPEG: Max 2160P@30fps
  • USB audio: Support
  • USB video communication protocol: UVC 1.1
  • USB PTZ Control: Support

IPC Features

  • Video Coding Standard: H.265/H.264/MJEPG
  • Video Stream: First Stream, Second Stream
  • First Stream Resolution: 3840x2160, 1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360
  • Second Stream Resolution: 640x360, 480x270, 320x240, 320x180
  • Video Bit Rate: 32 Kbps - 26624 Kbps
  • Rate Control: Variable Bit Rate, Fixed Bit Rate
  • Frame Rate: 50 Hz: 1fps - 25fps, 60 Hz: 1fps - 30fps
  • Audio Compression Standard: AAC
  • Audio Bit Rate: 96 Kbps, 128 Kbps, 256 Kbps
  • Supporting Protocols: TCP/IP, HTTP, RTSP, RTMP(S), ONVIF, DHCP,NTP and Multicast

Generic Specifications

  • Input Voltage: 48V PoE (802.3af)/DC 12V
  • Input Current: 12V 1.0A(Max)
  • Operating Temperature: -10°c – 40°c (14°F - 104°F)
  • Storage Temperature: -40°c – 60°c (-40°F - 140°F)
  • Power Consumption: 12W (Max)
  • Mean time between failures: >30000 hours
  • Dimension: 9.4 x 5.6 x 6.3” (240 x 144 x 160mm)
  • Weight: 4.6lb (2.1kg)

Optional Accessories

  • 910-2100-103: Wall Mount for UNITE 200 Camera
  • 910-2100-203: Ceiling Mount for UNITE 200 Camera
  • 910-2100-002: USB 3.0 Cable

Part Number

  • 910-2100-018
