- Supports all AV inputs for ultra high quality digital media distribution via your current IP network infrastructure to all endpoints.
- High profile H.264 codec with lossless compression, with 1080p60 resolution, 4:4:4 color space, HDCP for content protection
- Low bandwidth consumption and unlimited scalability
- Standards based streams that interoperates with 3rd party systems
- Software based system for video wall and video composition features that replace hardware video processors
Video
-
Digital Video Connection (Primary): HDMI 1.4b output
-
Digital Video Connection (Secondary): Mini Display Port 1.2 output
-
Supported Resolutions: 1080p60 1920×1080, HD720 1280×720, UXGA 1600×1200, WSXGA+ 1680×1050, SXGA+ 1440×1080 & 1440×1050, WXGA 1440×900, SXGA 1280×1024, XGA 1024×768, SVGA 800×600, VGA 640×480
-
Compression Standard: H.264/MPEG4 Part 10 (AVC) Baseline, Main, High profiles up to 4.2
-
Color Space Support: 24-bit RGB 4:4:4 YCbCr 4:2:0
Audio
-
HDMI
-
S/PDIF
-
Mini Display Port
-
USB (future)
Networking
-
10/100/1000 Mbps RJ45 (Gigabit)
General
-
Power: External Power Supply AC 100-240V input, DC 19V output, 3.42 A
-
Power: External Power Supply AC 100-240V input, DC 19V output, 3.42 A
-
SD Card Slot (future)
Mechanical
-
Dimensions (W x H x D): 1.26” × 4.37” × 4.53” (32mm × 111mm × 115mm)
-
Mounting: VESA mounting bracket (supports 75mm × 75mm and 100mm × 100mm)
-
Operating Temperature: 32 to 104 °F (0 to 40 °C)
-
Items Included: Power supply, VESA mounting bracket, USB to DB9 serial adapter
Software Licenses
-
StreamNet Audio license
-
Audio Mixing License
-
PANORAMA TM Video-Composition, Video-Wall license
-
3rd Party RTSP/UDP License
-
Local Playback License
