  • Supports all AV inputs for ultra high quality digital media distribution via your current IP network infrastructure to all endpoints.
  • High profile H.264 codec with lossless compression, with 1080p60 resolution, 4:4:4 color space, HDCP for content protection
  • Low bandwidth consumption and unlimited scalability
  • Standards based streams that interoperates with 3rd party systems
  • Software based system for video wall and video composition features that replace hardware video processors

Video

  • Digital Video Connection: X2 HDMI 1.4a input
  • Supported Resolutions:
    -1080p60 1920×1080
    -WUXGA 1920×1200 (scaled resolution)
    -HD720 1280×720
    -UXGA 1600×1200
    -WSXGA+ 1680×1050
    -SXGA+ 1440×1080 & 1440×1050
    -WXGA 1440×900
    -SXGA 1280×1024
    -XGA 1024×768
    -SVGA 800×600
    -VGA 640×480
    -X2 via HDMI input port
  • Compression Standard: H.264/MPEG4 Part 10 (AVC) Baseline, Main, High profiles up to 4.2
  • Color Space Support: 24-bit RGB 4:4:4 YCbCr 4:2:0
  • HDCP 2.1 Support: X2
  • Scaling Support

Audio

  • 2 CH Audio Encoding LPCM (Uncompressed) MPEG4 AAC-LC Sample Rate: (KHz); 11, 22, 24, 32, 44.1, 48, 96, 128,192 Bit Rates: (Kbps); 32, 96, 128,192, 320
  • 2 CH Balanced Analog Audio Input:
    -THD+N = .006% @20dBu
    -Dynamic Range: 106dB
    -Frequency Response: +/- 0.5dB (20->20KHz)
    -Crosstalk: -80dB
    -Removable Phoenix 3.55mm (3 pos × 2)
  • 2 CH Unbalanced Analog Audio Input
    -THD+N = -84dB, Dynamic Range = 90dBA
    -SNR = 95dBA
    -Crosstalk = -80dB, 3.5mm phone jack (T/S/R 3 pos.)
  • Digital Audio I/O: X2 input via HDMI ports
  • USB Audio: X1 input

Mechanical

  • Dimensions (W x H x D): 12.2” × 7.4” × 1.75” (310mm × 188mm × 44.4mm)
  • Weight (Unit): 5.3Lbs (2.4Kg)
  • Mounting: Wall Mount Rack Mount VESA mount 100x100 mm bracket
  • Operating Temperature: 32 to 104 °F (0 to 40 °C)
  • Items Included: Power supply Rack mount ears

Software Licenses

  • PANORAMA™ Video composition license
  • StreamNet Audio license
  • Audio Mixing License
  • RTSP/UDP streaming
  • Multicast RTSP/UDP License

VIEW Pro Accessories

  • VIEW Pro Rack mount
  • VIEW Pro Wall mount
  • VIEW Pro IR Receiver
  • VIEW Pro IR Receiver & Emitter
  • VIEW Pro VESA bracket

Networking, Channels and Protocols

  • 10/100/1000 RJ45: X2 Gigabit ports
  • Video Streams (Channels): Up to 2 1080p@60Hz or 1920×1200@57Hz
  • Audio Streams (Channels): Stereo or multi-ch pass through 4 Streams (2 Analog (Stereo) and 2 Digital (Stereo or multi-ch)
  • StreamNet Discovery & Control: Requires StreamNet 3.1x or higher

Control

  • Serial RS232 Port: DB9
  • IR Output: 3.5mm phone jack (T/R 3 pos.) (Compatible with StreamNet and other IR Emitters)
  • IR Input: 3.5mm phone jack (T/S/R 3 pos.) (Compatible with StreamNet IR Sensor only)
  • USB 3.0, 2.0: Future support
  • GPIO Inputs: X3, removable Phoenix 3.55mm (6 pos × 1) Contact Closure sensor input
  • GPIO Outputs: X3, removable Phoenix 3.55mm (6 pos × 1) Latching Relay Contact Closure output 20V@1A Max

General

  • Power: 19VDC / @2A Normal Operation / @6A Max
  • Rear Panel Power Button: Short press safe power cycle / long press forced shut down
  • Power LED Color Status:
    State | LED Color
    Normal | Blue
    Boot | Green
    Error | Red
    Upgrade | Amber
