Key Highlights

  • One COLLABORATE Pro 600 appliance with up to four-way conferencing.
  • One UNITE 200®PTZ camera to enjoy full HD 1080p / 60fps video, 12x optical zoom, and wide-angle view to capture all participants in the room.
  • Two CHAT® 150C speakerphones to converse clearly with adaptive acoustic modeling, first-microphone priority plus echo and noise cancellation.
  • Simultaneously capture up to four video input sources to maximize visual experience.
  • Complimentary 90-day COLLABORATE® Spontania, the premier cloud-based audio and video collaboration suite.

Applications

  • Audio and video conferencing
  • Interactive whiteboarding
  • Wireless presentation
  • Sharing, recording, and streaming

Environments

  • Meeting rooms
  • Training centers
  • Classrooms
  • Medium to large-size conference rooms

System includes

  • COLLABORATE Room Pro 600 codec
  • UNITE 200 PTZ camera
  • CHATAttach® 150 Speakerphone
  • Remote control
  • Spontania Cloud Meeting Room subscription (90 days)
  • Power supplies, cables and accessories
  • 4-way SIP/H.323 MCU license
  • Wireless presentation & collaboration (1-user license)

COLLABORATE Codec Appliance

  • Video inputs: 2x HDMI, 2x USB 3.0
  • Video outputs: 1x HDMI, 1x Display port
  • Audio inputs: Balanced audio, USB, Line in
  • Audio outputs: Balanced audio, Line out, HDMI
  • Dimensions: 17 x 8 x 2 ½ (L x W x H)

UNITE 200 USB PTZ Camera

  • 12x Optical zoom
  • 73° wide-angle view with auto-focus
  • USB 3.0, HDMI, & IP output
  • Full HD 1080p 60fps
  • Control: Remote control, USB (UVC), RS-232
  • Pan/Tilt Angles: ±170°, Tilt: -30° to +90°

Video Characteristics

  • Resolution up to 1080p @ 60 fps
  • H.261, H.263, H.263+/++
  • H.264/AVC High Profile – up to 6Mbps
  • H.264/SVC (Skype for Business)

Audio Standards

  • 20KHz: AAC-LD
  • 14KHz: G.722.1 Annex C
  • 7KHz: G.722, G.722.1
  • 3.4KHz: G.711, G.723.1, G.728. G.729. AMR (3G)

Data Characteristics

  • H.239 support for data sharing
  • Resolution up to 1080p
  • Data inputs via HDMI, Wireless, USB

Recording

  • Formats: MP4, WMV
  • Storage options: Local, external, network (NAS)

Streaming

  • Format: RTSP – Unicast and multicast streaming
  • Max number of viewers (unicast): 20
  • Max number of viewers (multicast): Depends on network Note: Streaming is not supported in Spontania session

Control

  • Remote control
  • Web-based management and control
  • Telnet API for 3rd party control
  • AMX and Crestron modules

Directory Services

  • 1000+ local number directory
  • 10,000+ global number directory
  • H.350 support (thru COLLABORATE Central)
  • LDAP online directory support
  • OpenLDAP
  • Active Search and Filter queries

Environments

  • Operating Temperature: 32° to 104° F (0° to 40 °C) *At temps higher than 35°C, other environmental conditions may apply

Shipping Package Specifications

  • Dimension: 22 x 14.5 x 17.5 (inches)
  • Weight: 25 lbs

Part Number

  • 930-3001-600
