POWER: Power status indicator Blue light indicates power on
CLIP: Clip status indicator Red light indicates clip status due to:
- Input is too high, signal clip
- Output peak detected
SIGNAL PRESENT: Signal indicator Blue light indicates signal is present or passing out
STANDBY: Standby mode status indicator Yellow light indicates Standby mode enables when no audio is present. The amplifier first enters Mute mode at 2 minutes, then into Standby mode at 10 minutes.
LIMIT: Limit indicator Red light indicates gain reduction activation
PROTECT/DISABLE: Protection or Disable status indicators Red light indicates Disabled/Mute/Protection mode Mute mode enables when no audio is present for 2 minutes Protection mode enables when a temperature exceeds 185°F (85°C)
Power & Thermal
Power Consumption: 42W Typical, Pink Noise @ 0 dBu, 8Ω
Power Supply: AC input 100-240VAC, 50Hz/60Hz
Thermal: 143 BTU/Hr Typical
Temperature: 14°F to 104°F (-10°C to 40°C) (Ambient temperature)
Dimensions & Weight
Dimensions: 8.38” (213mm) W x 11.06” (281mm) D x 1.72” (44mm) H
