COMPATIBLE WITH
Enhance Your Cloud Collaboration
Key Highlights
- Full HD 1080p30 video, 12x optical zoom, and capability to capture all participants in the room
- Compatible with popular applications such as COLLABORATE® Space, Microsoft® Teams, WebEx™, Zoom™, GoToMeeting™, and more
- Control the camera’s functions via IR remote, RS-232, or UVC protocol.
- Transforms any meeting room into a professional-grade video collaboration room
- Super-high SNR with advanced 2D and 3D noise reduction
- Simple USB 3.0/2.0 compatibility with UVC and UAC protocol support.
Applications
- PC-based video conferencing
- Web conferencing
- Unified communications
- Capture applications and more
Environments
- Huddle spaces
- Executive offices
- Conference rooms
- Boardrooms
- Training centers
CAMERA
- Video System:
• HD: 1080p30
• 1080p25
• 720p30
• 720p25 - Sensor: 1/2.7 inch, CMOS
- Effective Pixel: 2.07M
- Scanning Mode: Progressive
- Lens : 12x, f3.5MM – 42.3MM, f1.8 – f2.8
- Focus Mode: Auto Focus
- Minimal Illumination : 0.5 l ux @ (f1.8, Agc On)
- Shutter : 1/30S – 1/10000S
- White Balance : Auto , Indoor, Outdoor, One Push, Manual
- Backlight Compensation : Supported
- Digital Noise Reduction : 2D & 3D Digital Noise Reduction
- Video S/N : ≥55dB
- Horizontal Angle of View : 72.5° – 6.9°
- Vertical Angle of View : 44.8° – 3.9°
- Horizontal Rotation Range : ±170°
- Vertical Rotation Range : -30° – +90°
- Pan Speed Range : 1.7° – 100°/S
- Tilt Speed Range : 1.7° – 69.9°/S
- H & V FLIP : Supported
- Image Freezing : Supported
- Number of Presets : 255
- Flexible Installation : Stand Mount, upside-down mount
Input/Output Interface
- Audio Interface : 1-CH 3.5MM Audio Interface, Line In
- USB Interface : 1 x USB3.0: type B Female jack
- Communication :
- 1 x RS-232 : 8 - Pin Min din, Max. Distance: 30 m,
Protocols: VISCA/Pelco-D/Pelco-P
- 1 x RS-485 : 2 - Pin Phoenix port; Max. Distance: 1200 m,
Protocols: VISCA/Pelco-D/Pelco-P
USB FEATURES
- Operating Systems: Windows 7, Windows 8, Window 8.1, Windows 10, MacOS, Linux
- Color System: YUV 4:2:2
- Video Formats:
• USB3.0: 1080p30
• 1080p25
• 720p30
• 720p25 - USB 2.0: 720P30 maximum
- NOTE:Due to limitations with USB 2.0, video quality would be downgraded. USB 2.0 extenders are not recommended.
- USB Video Communication: UVC 1.0 - UVC 1.5
- Audio on USB: Supported
- UVC PTZ: Supported
GENERIC SPECIFICATIONS
- Power Jack : Jeita Type (DC in 12v)
- Input Voltage : DC 12v
- Current Consumption : 1.0A (MAX)
- Power Consumption: 12w (max)
- Operating Temperature True : -14°F–104°F (-10°C – 40°C)
- Storage Temperature : -40°F – 140°F (-40°C – 60°C)
- MTBF: >30000h
- Dimension : : 5.67” x 5.67” x 6.61” (144mm x 144mm x 168mm)
- Weight : 2.0lb (0.91Kg)
OPTIONAL ACCESSORIES
- 910-2100-104: Wall Mount for UNITE 150 Camera
- 910-2100-204: Ceiling Mount for UNITE 150 Camera
- 910-2100-002: USB 3.0 cable
PART NUMBER
- 910-2100-004
Related Products
Other products that may interest you
Unite 150 FAQs
What type of camera is the UNITE 150?
The UNITE 150 is a professional-grade HD USB PTZ (Pan-Tilt-Zoom) camera designed for conference rooms and web conferencing.
What applications is the UNITE 150 camera suitable for?
It is suitable for web conferencing, UC (Unified Communications) applications, and other professional video conferencing needs.
What is the main advantage of using a PTZ camera like the UNITE 150?
PTZ functionality allows users to pan, tilt, and zoom the camera for optimal coverage and detailed video capture during meetings.
How does the UNITE 150 camera connect to a system?
It connects via USB, ensuring compatibility with a range of conference room setups.
