COMPATIBLE WITH
Enhance Your Cloud Collaboration
Smart Face Tracking or Auto Framing. AI processing optionally tracks an individual or frames an entire group for perfect framing and focus.
Key Highlights
- 4K Ultra HD video, 12x optical zoom, capability to capture all participants in the room.
- Super-high SNR with advanced 2D and 3D noise reduction.
- Transforms any meeting room into a professional grade video collaboration room.
- Compatible with popular applications such as Zoom, WebEx, Google® Meet™, and more.
- Control the camera’s functions via IR remote, RS-232, or UVC protocol.
- Simple USB 3.0/2.0 compatibility with UVC and UAC protocols support.
Applications
- Camera Tracking for Lecture Capture
- Web Conferencing
- Unified Communications
Workspaces
- Conference Rooms
- Executive Offices
- Training Centers
- Classrooms
Smart Face Tracking or Auto Framing. AI processing optionally tracks an individual or frames an entire group for perfect framing and focus.
Camera
- Video System:
- 2160p30
- 1080p30
- 1080p25
- 720p30
- 720p25
- Sensor: 1/2.5 inch, CMOS
- Effective Pixels: 8.51 Million
- Scanning Mode: Progressive
- Lens: 12x maximum zoom, Focal length: 4.4 mm - 52.8 mm, F1.8 - F2.6
- Minimal Illumination: 0.5 Lux @ (F1.8, AGC ON)
- Shutter: 1/30s – 1/10000s
- White Balance: Automatic, indoor, outdoor, one-button, manual, specified color
- Backlight Compensation: Supported
- Digital Noise Reduction: 2D & 3D
- Video S/N: ≥55dB
- Horizontal Angle of View: 71° – 8.2°
- Vertical Angle of View: 42.7° – 4.5°
- Horizontal Rotation Range: ±170°
- Vertical Rotation Range: -30° – +90°
- Pan Speed Range: 2.7° – 35.7°/s
- Tilt Speed Range: 2.7° – 31.5°/s
- H & V Flip: Supported
- Image Freezing: Supported
- Number of Presets: 255
- Flexible Installation: Standard mount, upside-down mount
Input/Output Interface
- Audio Interface: 3.5 mm connector, Line In
- USB Interface: 1 way, USB 3.0, Type C Socket
- 1 x RS232: 8pin Min DIN; Max. Distance: 30 m;
Protocol: VISCA/Pelco-D/Pelco-P - 1 x RS485: 2pin phoenix port; Max. Distance: 1200 m;
Protocol: VISCA/Pelco-D/Pelco-P
USB Features
- Operating Systems: Windows 7 and later
- Color System: YUY2 / MJPEG
- USB 2.0: 720P30 maximum
NOTE: Use of USB 2.0 downgrades video quality. ClearOne does not recommended USB 2.0 extenders - USB Video Communication: UVC 1.1
- Audio on USB: Supported
- UVC PTZ: Supported
Power
- Power Jack: JEITA type (DC In 12V)
- Input Voltage: DC 12V
- Current Consumption: 1.0A (max)
- Power Consumption: 12W (max)
Environmental
- Operating Temperature: 14°F–104°F (-10°C – 40°C)
- Storage Temperature: -40°F – 140°F (-40°C – 60°C)
- MTBF: >30000h
Mechanical
- Dimensions: 5.67” x 5.67” x 6.61” (143.88mm x 144mm x 168.25mm)
- Weight: 3.5lb (1.6Kg)
Part Number
- 910-2100-012
Optional Accessories
- 910-2100-104: Wall Mount for UNITE 150 Camera
- 910-2100-204: Ceiling Mount for UNITE 150 Camera
- 910-3200-702-30: USB 3.0 cable
