COMPATIBLE WITH
Enhance Your Cloud Collaboration
Smart Face Tracking or Auto Framing. AI processing optionally tracks an individual or frames an entire group for perfect framing and focus.
Key Highlights
- 4K Ultra HD video, 12x optical zoom, capability to capture all participants in the room.
- Super-high SNR with advanced 2D and 3D noise reduction.
- Transforms any meeting room into a professional grade video collaboration room.
- Compatible with popular applications such as Zoom, WebEx, Google® Meet™, and more.
- Control the camera’s functions via IR remote, RS-232, or UVC protocol.
- Simple USB 3.0/2.0 compatibility with UVC and UAC protocols support.
Applications
- Camera Tracking for Lecture Capture
- Web Conferencing
- Unified Communications
Workspaces
- Conference Rooms
- Executive Offices
- Training Centers
- Classrooms
Smart Face Tracking or Auto Framing. AI processing optionally tracks an individual or frames an entire group for perfect framing and focus.
Camera
- Video System:
- 2160p30
- 1080p30
- 1080p25
- 720p30
- 720p25
- Sensor: 1/2.5 inch, CMOS
- Effective Pixels: 8.51 Million
- Scanning Mode: Progressive
- Lens: 12x maximum zoom, Focal length: 4.4 mm - 52.8 mm, F1.8 - F2.6
- Minimal Illumination: 0.5 Lux @ (F1.8, AGC ON)
- Shutter: 1/30s – 1/10000s
- White Balance: Automatic, indoor, outdoor, one-button, manual, specified color
- Backlight Compensation: Supported
- Digital Noise Reduction: 2D & 3D
- Video S/N: ≥55dB
- Horizontal Angle of View: 71° – 8.2°
- Vertical Angle of View: 42.7° – 4.5°
- Horizontal Rotation Range: ±170°
- Vertical Rotation Range: -30° – +90°
- Pan Speed Range: 2.7° – 35.7°/s
- Tilt Speed Range: 2.7° – 31.5°/s
- H & V Flip: Supported
- Image Freezing: Supported
- Number of Presets: 255
- Flexible Installation: Standard mount, upside-down mount
Input/Output Interface
- Audio Interface: 3.5 mm connector, Line In
- USB Interface: 1 way, USB 3.0, Type C Socket
- 1 x RS232: 8pin Min DIN; Max. Distance: 30 m;
Protocol: VISCA/Pelco-D/Pelco-P - 1 x RS485: 2pin phoenix port; Max. Distance: 1200 m;
Protocol: VISCA/Pelco-D/Pelco-P
USB Features
- Operating Systems: Windows 7 and later
- Color System: YUY2 / MJPEG
- USB 2.0: 720P30 maximum
NOTE: Use of USB 2.0 downgrades video quality. ClearOne does not recommended USB 2.0 extenders - USB Video Communication: UVC 1.1
- Audio on USB: Supported
- UVC PTZ: Supported
Power
- Power Jack: JEITA type (DC In 12V)
- Input Voltage: DC 12V
- Current Consumption: 1.0A (max)
- Power Consumption: 12W (max)
Environmental
- Operating Temperature: 14°F–104°F (-10°C – 40°C)
- Storage Temperature: -40°F – 140°F (-40°C – 60°C)
- MTBF: >30000h
Mechanical
- Dimensions: 5.67” x 5.67” x 6.61” (143.88mm x 144mm x 168.25mm)
- Weight: 3.5lb (1.6Kg)
Part Number
- 910-2100-012
Optional Accessories
- 910-2100-104: Wall Mount for UNITE 150 Camera
- 910-2100-204: Ceiling Mount for UNITE 150 Camera
- 910-3200-702-30: USB 3.0 cable
Video Gallery
UNITE 160 4K Camera Video
Related Products
Other products that may interest you
Unite 160 Camera FAQs
What sets the UNITE 160 Camera apart from other conference cameras?
The UNITE 160 Camera is an AI-powered 4K USB PTZ camera designed to deliver superior video quality and smart features for video conferencing.
Is the UNITE 160 Camera compatible with common video conferencing platforms?
Yes, it works with popular platforms like Microsoft Teams, Zoom, and other major conferencing tools.
What control options does the UNITE 160 Camera offer?
It provides multiple control options, allowing for versatile and efficient management of the camera's pan, tilt, and zoom functions.
Is the UNITE 160 Camera suitable for all conference room sizes?
Yes, it is designed to be perfect for any conference room, offering advanced AI features to enhance the meeting experience.
