Supports all AV inputs for ultra high quality digital media distribution via your current IP network infrastructure to all endpoints.

Key Highlights

  • High profile H.264 codec with lossless compression, with 1080p60 resolution, 4:4:4 color space, HDCP for content protection
  • Low bandwidth consumption and unlimited scalability
  • Standards based streams that interoperates with 3rd party systems
  • Software based system for video wall and video composition features that replace hardware video processors

Applications

  • Corporate announcements
  • Live streaming
  • Digital signage
  • Telemedicine

Workspaces

  • Workplaces
  • Schools
  • Command & Control centers
  • Healthcare facilities
  • Hospitality & Entertainment centers
  • Houses of Worship
  • Transportation hubs

Supports all AV inputs for ultra high quality digital media distribution via your current IP network infrastructure to all endpoints.

Ultra High-Quality Video

  • + High profile H.264 lossless compression

    + Full HD 1080p60 resolution

    + 24-bit true color with 4:4:4 color space

    + Ultra low latency—end-to-end

    + Full HDCP support

Unlimited Scalability

  • + Any number of inputs & outputs in any combination

    + One source to many displays

    + Many sources to one display

    + Many sources to many displays

Flexible Control

  • + VIEW Virtual Matrix control application

    + Matrix view of all live sources & destinations

    + In-room controller - touch panel & web

    + 3rd-party control - AMX, Crestron, Utelogy

Standards-based

  • + Existing IP network infrastructure

    + Uses standard CAT 5e/6 cabling

    + Interoperates with 3rd-party systems

    + RTSP/UDP streaming

Video Composition & Video Wall

  • + Software license (one time, per unit)

    + Video-wall, Video-windowing, video-composition

    + Layout management

    + Text overlay, screen rotation

Configuration & Management

  • + Auto-discovery of encoders & decoders

    + Device configuration & management

    + Project management

    + System monitoring & troubleshooting

Supports all AV inputs for ultra high quality digital media distribution via your current IP network infrastructure to all endpoints.

Video

  • Digital Video Connection (Primary): HDMI 1.4b output
  • Digital Video Connection (Secondary): Mini Display Port 1.2 output
  • Supported Resolutions: 1080p60 1920×1080, HD720 1280×720, UXGA 1600×1200, WSXGA+ 1680×1050, SXGA+ 1440×1080 & 1440×1050, WXGA 1440×900, SXGA 1280×1024, XGA 1024×768, SVGA 800×600, VGA 640×480
  • Compression Standard: H.264/MPEG4 Part 10 (AVC) Baseline, Main, High profiles up to 4.2
  • Color Space Support: 24-bit RGB 4:4:4 YCbCr 4:2:0

Audio

  • HDMI
  • S/PDIF
  • Mini Display Port
  • USB (future)

Networking

  • 10/100/1000 Mbps RJ45 (Gigabit)

General

  • Power: External Power Supply AC 100-240V input, DC 19V output, 3.42 A
  • Power: External Power Supply AC 100-240V input, DC 19V output, 3.42 A
  • SD Card Slot (future)

Mechanical

  • Dimensions (W x H x D): 1.26” × 4.37” × 4.53” (32mm × 111mm × 115mm)
  • Mounting: VESA mounting bracket (supports 75mm × 75mm and 100mm × 100mm)
  • Operating Temperature: 32 to 104 °F (0 to 40 °C)
  • Items Included: Power supply, VESA mounting bracket, USB to DB9 serial adapter

Software Licenses

  • StreamNet Audio license
  • Audio Mixing License
  • PANORAMA TM Video-Composition, Video-Wall license
  • 3rd Party RTSP/UDP License
  • Local Playback License
